Ayrton Launches IP65-rated Domino Wash

Ayrton launches Domino Wash, its first IP65-rated wash fixture.

Ayrton presents Domino Wash, its first IP65-rated wash fixture, which has been developed for outdoor use. This professional, smart luminaire opens up a whole new world of versatility for concerts, performing arts, theme parks, and film shoots, the company says.

Domino Wash has a 210 mm Fresnel lens with a specific optical structure designed to accurately adapt the diffusion level according to requirements. This optical combination not only favors the use of framing shutter blades or geometric gobos, but significantly improves color mix and can produce 10% more light than with a classic Fresnel lens F.O.S.

To cover all types of use, Domino Wash is available in three flicker-free versions, S, TC and the entirely new ST or "Stage & Theatre" version. The ST version is fitted with a new monochromatic LED source that delivers a light output of 45,000 lumens and a D65 white point that allows perfect colour reproduction with a CRI greater than 80.

In common with many other Ayrton fixtures, the "Stage" or "S" version provides a cooler, metallic light with a record luminous flux of 52,000 lumens, a color temperature of 7,000K and a CRI of 70. The "True Colour" or "TC" version offers a color rendering index greater than 95 with extremely high TM30 values and a color temperature of 6,000 Kelvin to deliver perfect color rendering.

Domino Wash's proprietary optical system delivers a 12:1 zoom ratio and a zoom range of 6.2° at half peak to 75° at one-tenth peak. It shares the same complex colour mixing system with Huracán Wash, offering a double level of CMY saturation that can obtain 281 trillion colours and a triple corrector for variable colour temperature, allowing subtle adjustment from 2700 K to 15000 K and significant CRI improvement T.C.S.

Like all Ayrton products, Domino Wash is factory-equipped with full features. These include a 4-shutter framing section for accurate shutter cuts across a 100% surface area in all positions; a wheel of seven rotating glass gobos, a 15-blade iris diaphragm, a frost and an RGB & CMY animation wheel. Domino Wash also has Ayrton's liquid cooling system fitted with six submersible fans outside its weatherproof enclosure.

An all-terrain luminaire developed for resisting hot or cold weather, wind, rain, hail, sand or dust, Domino Wash aims to create unprecedented, incomparable and simply stunning atmospheres.

Domino Wash forms an exceptional trilogy with Domino Profile and Domino LT and is the latest addition to Ayrton's Classical 9 Series range.

Full specifications and a promotional video for Domino Wash can be found on the Ayrton website vimeo.com/798530990 along with information on Ayrton's full range of LED and laser sourced lighting fixtures.


(14 February 2023)
